STEP UP
SCALE A GABBIA
Realizzate in lega di alluminio, offrono elevata resistenza meccanica, alla corrosione e agli agenti atmosferici.
Garantiscono all’utilizzatore la massima sicurezza e all’installatore la tranquillità di un prodotto affidabile e facile da montare.
Grazie alla vasta gamma di componenti, il sistema modulare risponde ad ogni esigenza progettuale
Documentazione
-
Scheda Tecnica
-
Norme di sicurezza, istruzioni di utilizzo e d’installazione
MODULI SCALA
| CODICE | descrizione | B
[mm]
|
L
[mm]
|
H
[mm]
|
pz. |
|---|---|---|---|---|---|
| STEPMOD120 | ladder module 1,20 m - 4 steps | 65 | 636 | 1200 | 1 |
| STEPMOD150 | ladder module 1,50 m - 5 steps | 65 | 636 | 1500 | 1 |
| STEPMOD180 | ladder module 1,80 m - 6 steps | 65 | 636 | 1800 | 1 |
| STEPMOD210 | ladder module 2,10 m - 7 steps | 65 | 636 | 2100 | 1 |
| STEPMOD240 | ladder module 2,40 m - 8 steps | 65 | 636 | 2400 | 1 |
| STEPMODCAP | pair of upper upright caps | - | - | - | 1 |
| STEPMODJUN | pair of ladder-to-ladder joints | 21 | 62 | 240 | 1 |
USCITE FRONTALI
| CODICE | descrizione | B
[mm]
|
L
[mm]
|
H
[mm]
|
pz. |
|---|---|---|---|---|---|
| STEPOUT160 | module with front exit rail 1,6 m - 2 steps | 65 | 636 | 1595 | 1 |
| STEPOUT190 | module with front exit rail 1,9 m - 3 steps | 65 | 636 | 1895 | 1 |
| STEPOUT220 | module with front exit rail 2,2 m - 4 steps | 65 | 636 | 2195 | 1 |
| STEPOUT250 | module with front exit rail 2,5 m - 5 steps | 65 | 636 | 2495 | 1 |
| STEPOUTJUN | pair of ladder joints-front exit rail | 21 | 62 | 240 | 1 |
GABBIA
| CODICE | descrizione | B
[mm]
|
L
[mm]
|
H
[mm]
|
pz. |
|---|---|---|---|---|---|
| STEPBARJUN | kit with 5 rod joints for cage | 18 | 22 | 80 | 1 |
ANELLI
| CODICE | descrizione | B
[mm]
|
L
[mm]
|
H
[mm]
|
pz. |
|---|---|---|---|---|---|
| STEPRINGIT | cage ring Leg. Decree 81/2008 - UNI 11962:2024 | 660 | 636 | 44 | 1 |
| STEPRINGEU | cage ring EN 14122 | 760 | 636 | 44 | 1 |
| STEPRINGJUN | pair of ladder-to-ring joints for cage | 36 | 61 | 36 | 1 |
| STEPSUPRING | pair of reinforcements between steps and safety cage | 340 | 51 | 340 | 1 |
STAFFE
| CODICE | descrizione | B
[mm]
|
L
[mm]
|
H
[mm]
|
pz. |
|---|---|---|---|---|---|
| STEPBRAF150 | pair of mounting brackets for a 150 mm wall distance | 269 | 88 | 50 | 1 |
| STEPBRAV400 | pair of mounting brackets for an adjustable wall distance - max. 400 mm | 474 | 88 | 55 | 1 |
| STEPBRAV600 | pair of mounting brackets for an adjustable wall distance - max. 600 mm | 674 | 88 | 55 | 1 |
| STEPBRAMET | pair of mounting plates for trapezoidal metal (fasteners included) | 150 | 358 | 32 | 1 |
TAPPI
| CODICE | descrizione | pz. |
|---|---|---|
| STEPMODCAP | pair of upper upright caps | 1 |
| STEPBARCAP | kit with 5 rod caps | 1 |
PEDANA PER SDOPPIAMENTO
| CODICE | descrizione | pz. |
|---|---|---|
| STEPBOARIT | splitting platform Legislative Decree 81/2008 - UNI 11962:2024 | 1 |
| STEPBOAREU | splitting platform EN 14122 | 1 |
TARGHETTA
| CODICE | descrizione | pz. |
|---|---|---|
| STEPTARGAEU | label EN 14122-4 + EN manual | 1 |
| STEPTARGAIT | label Leg. Decree 81/2008 - UNI 11962:2024 + IT manual | 1 |
ACCESSO SCALA
| CODICE | descrizione | pz. |
|---|---|---|
| STEPTRAPEU | safety gate for ladder access EN 14122 | 1 |
| STEPTRAPIT | safety gate for ladder access Legislative Decree 81/2008 - UNI 11962:2024 | 1 |
| STEPDOOR90 | half-height safety door complete with fasteners and door stop | 1 |
| STEPDOOR180 | safety door | 1 |
| STEPDOORUP | upper part of safety door | 1 |
CHIUSURA
| CODICE | descrizione | pz. |
|---|---|---|
| STEPCOVEREU | metal sheet to cover the safety cage EN 14122 | 1 |
| STEPCOVERIT | metal sheet to cover the safety cage Legislative Decree 81/2008 - UNI 11962:2024 | 1 |
| STEPCOVERSIDE | pair of side cage covers | 1 |
KIT PROTEZIONE
| CODICE | descrizione | pz. |
|---|---|---|
| STEPLAND300 | 300 mm platform kit with side protection | 1 |
| STEPLAND500 | 500 mm platform kit with side protection | 1 |
| STEPLAND800 | 800 mm platform kit with side protection | 1 |
| STEPLAND1000 | 1000 mm platform kit with side protection | 1 |
ACCESSORI E BASI
| CODICE | descrizione | pz. |
|---|---|---|
| STEPDOORDIST | - | 1 |
| STEPFEETREG | pair of adjustable support feet with holes for possible ground fastening | 1 |
| STEPFEETHING | pair of hinged feet with adjustable supports | 1 |
CANCELLETTI
| CODICE | descrizione | pz. |
|---|---|---|
| STEPGATE550 | landing gate H=550 mm (fasteners included) | 1 |
| STEPGATEKIT | fastening kit for duplication of STEPGATE550 gate | 1 |
